Okta

1. Select Enable Administrators to log in to the portal using this IdP.

2. Select one of these options:

   • Login based on domain verification - Infinity Portal Administrators can log in to this Infinity Portal account with SSO from the Identity Provider A system entity that creates, maintains, and manages identity information for principals and also provides authentication services to relying applications within a federation or distributed network. Acronym: IdP or IDP.. Administrators log in through the Infinity Portal login page.

   • Login with a unique URL - Infinity Portal Administrators can log in to multiple Infinity Portal accounts with SSO from the Identity Provider. Administrators log in using the URL that appears at the bottom of the Login with a unique URL section. Copy this URL and keep it in a safe place.

1. In the Service(s) Integration section, select one of these options:

   • No Services - End users of Infinity Portal services cannot authenticate with SSO from the Identity Provider. This is the default configuration.

   • All Services - End users can log in with SSO from the Identity Provider to all Check Point services that support SSO.

   • Specific Service(s) - From the list of services, select service(s) to allow end users to log into with SSO from the Identity Provider. Available services:

     • Harmony Connect

     • Quantum Gateways

2. Click Next (or, if you are editing a configuration, Apply) to complete the Integration Type configuration.

1. Log in to your Okta Portal.

2. Click Admin.

3. From the left taskbar, click Applications > Applications.



   The Applications screen opens.

4. Click Create App Integration.



   The Create a new app integration window opens.

5. Select SAML 2.0 and click Next.



   The Create SAML Integration window opens.

6. In the General Settings tab > App name field, set the application name to Check Point Infinity Portal and click Next.



   The Configure SAML tab opens.

1. In the Okta Portal > Configure SAML tab > SAML Settings menu > General section, configure SAML Security Assertion Markup Language. An XML-based, open-standard data format for exchanging authentication and authorization data between parties, in particular, between an identity provider and a service provider. settings.

2. Copy the Single sign-on (Destination URL) from the Infinity Portal to the Single sign-on URL field in the Okta Portal.

3. In the Okta Portal, make sure that Use this for Recipient URL and Destination URL is selected. This option is selected by default.

4. Copy the Audience URL (SP Entity ID) from the Infinity Portal to the Audience URI (SP Entity ID) field in the Okta Portal.

5. In the Okta Portal > Name ID format field, select EmailAddress.

6. In the Okta Portal > Application username field, make sure that Okta username is selected.

IdP Initiated flow lets you connect directly to Infinity Portal from the Okta portal. To do this, you must create an Infinity Portal app card in the Okta portal. See the Okta documentation for App integrations.

To configure IdP Initiated flow, copy the Default Relay State from the Infinity Portal to the Default Relay State field in the Okta Portal.

1. In the SAML Settings menu > Attribute Statements section, create these attribute statements:

   • Name - firstName

     Name format - unspecified

     Value - user.firstName

   • Name - lastName

     Name format - unspecified

     Value - user.lastName

   • Name - userId

     Name format - unspecified

     Value - user.id

2. In the SAML Settings menu > Group Attribute Statements section, create this group attribute statement:

   Name - groups

   Name format - Basic

   Filter - Matches regex

   Value (this field does not have a name) - .*



   Important - Copy the name of the assigned group for use with the Check Point Infinity Portal User Group IdP ID field.

3. Select This is an internal app that we have created and then click Finish.

1. In the Okta Portal, open the application you created for the Infinity Portal:

   1. From the left taskbar, click Applications > Applications.

      The Applications screen opens.

   2. Open the application you created for the Infinity Portal.

2. Open the Sign On tab.

3. In the SAML Signing Certificates section > table row of the active SAML certificate, click Actions > View IdP Metadata.



   A new window opens with the metadata.

4. Save the metadata in a new file named InfinityPortalOktaMetaData.XML.

1. In the Infinity Portal, click Select File and upload the metadata XML file.

   Note - Check Point uses the service URL and the name of your Certificate to identify your users behind the sites.

2. Click Next / Apply.

   Check Point verifies the metadata for Okta.

Set up permissions to allow a selection of users and user groups from your Okta directory in the Infinity Portal Policy.

1. In the Set Directory Integration step, select Manual API Sync and enter the details from your Okta account.

   1. In the Okta Portal, check your Okta domain. Usually, this name appears in the address bar and in your account name.

   2. Click the icon to the right of the Okta domain name to copy it.

   3. Paste the Okta domain name in the Okta Domain field on the Set Directory Integration page of the Identity Provider wizard.

   4. In the Okta Portal, navigate to Security > API > Tokens > click Create Token.



   5. In the window that opens, enter the token name and click Create Token.

   6. Copy the Token Value.

      Best Practice - Check Point recommends that you save the Token Value in a separate, secured file to retrieve when required.

   7. In the Infinity Portal Identity Provider wizard, on the Set Directory Integration page, paste the Token Value into the API Token Value field.

   8. To test the users and group synchronization between the Infinity Portal and the IdP, click Test Connectivity.

      If the test is unsuccessful, repeat the Set Directory Integration step to configure the user and group synchronization parameters.

   9. Click Next.

Prerequisites:

You must have An Okta account with administrator permissions and a SCIM provisioning subscription.

Step 1 - Configure the Directory Integration in the Infinity Portal:

1. In the Set Directory Integration step, select Automatic Sync SCIM.



2. Copy and save the SCIM API Token and URL.

3. Click Next.

4. Click Submit.

Step 2 - Configure the Application Integration in the Okta Admin Console:

1. Navigate to your Okta account and go to Applications.

2. Open the application you created for the Infinity Portal.

3. Enable SCIM provisioning:

   1. Click Edit.

   2. Select Enable SCIM provisioning.

   3. Click Save.

4. Create the SCIM connection:



   1. Click Edit.

   2. For SCIM connector base URL, enter the URL from the Set Directory Integration step in the Infinity Portal.

   3. For Unique identifier field for users, enter userName.

   4. For Supported provisioning actions, enable these settings:

      • Push New Users

      • Push Profile Updates

      • Push Groups

   5. For Authentication Mode, from the down arrow, select HTTP Header and paste the API token.

   6. Click Save.

5. Click Test Connector Configuration.

   Important - To test connectivity, you must first complete Step 1 - Configure the Directory Integration in the Infinity Portal: in its entirety.

   If the integration is configured correctly, then the Test Connector Configuration window shows Connector configured successfully.

6. From the top toolbar, select Provisioning, and below Settings select To app.



7. Enable these settings:

   • Create Users

   • Update User Attributes

   • Deactivate Users

8. Click Save.
